ZWCAD Mechanical 2023 SP1
ZWCAD Mechanical 2023 SP1 (x64) | 924.1 Mb

ZWCAD Mechanical for manufacturing provides abundant tools such as shaft generator, tolerance dimension, surface texture symbol, balloon and BOM and standards parts for mechanical 2D sheet drawing.


Power Dimension
Power Dimension makes dimensioning easier with abbreviated dialog boxes that control and expand only the variables that are relevant to manufacturing, as well as integrate tolerance and fit list information.

Multiple Dimensions
With Multiple Dimensions, you can create multiple dimensions with minimal input and properly space ordinate, parallel or symmetric items.

Detect dimension overlap and determine suitable distance
Overlapping dimensions can be automatically spaced apart appropriately. It determines the suitable distance from the object being dimensioned, making the linear dimensions look neat and clear..

Quickly design by using mechanical symbols
Mechanical symbols, include surface texture symbols, datum identifiers and targets, taper, center hole and weld symbols greatly save your time and improve your design accuracy.

Easily generate balloons and BOM
With ZWCAD Mechanical, you can draw, align and renumber standard-based balloons easily. It only takes one step to create a BOM. Also, it automatically recognizes standard parts and summarizes them to the BOM.

Associative Balloon and BOM
Every change to the balloon would be updated to the BOM, ensuring that the data is always correct and up-to-date.

Enterprise and international standards support
ZWCAD Mechanical supports ISO, ANSI, DIN, JIS and GB drawing environments, and it also provides an easy way to customize enterprise standards.

Layer management and layer mapping
Every mechanical entity, such as border, dimension, symbol, etc, would be placed to the default layer with preset color and linetype. With layer mapping, mechanical entity can be placed on a custom layer to match company practices.
