TimingDraw™ is a powerful editor for digital and analog timing diagrams with extensive features.
TimingDraw allows designers, scientists, and students to specify and visualize timing diagrams. In contrast to other timing editors, TimingDraw has some outstanding features, for example quick edit functions.
Intuitive Windows Graphical User Interface.
Digital and analog signals supported.
Logical signals, busses, clocks, analog signals.
Easy and interactive zoom/ unzoom by mouse wheel and mouse drag.
Save/ load projects.
Save as web page.
Open remote projects on the internet.
Export/ import of traces.
Labels and text supported.
Graphics (arrows, boxes, circles, curves).
Inversion of signals.
Cut, Copy, Paste of traces.
Edge help lines.
Save as Bitmap, copy to clipboard.
Send timing diagrams via eMail.
